Frequent loading and unloading of
compressor which fluctuates the air
pressure
Prevent unloading more than once per
minute.
Frequent starting and stopping of
compressor
See chapter starting-up the dryer.
Piston compressor feeding the dryer
giving a rapid pulsing air feed
Install pressure vessel in front of dryer.
10 Technical Data
Reference conditions
Compressed air effective inlet pressure bar 7
Compressed air effective inlet pressure psi 100
Compressed air inlet temperature °C 37.8
Compressed air inlet temperature °F 100
Inlet relative humidity of compressed air % 100
Pressure dewpoint
-40 °C Variant °C -40
-40 °F Variant °F -40
-70 °C Variant °C -73.3
-100 °F Variant °F -100
Limitations
Maximum compressed air effective inlet pressure
-CD 350+ up to CD 1400+ bar 10.5
-CD 350+ up to CD 1400+ psi 152
Minimum compressed air effective inlet pressure
-CD 350+ up to CD 1400+ bar 4.5
-CD 350+ up to CD 1400+ psi 65.3
Maximum ambient air temperature °C 40
Maximum ambient air temperature °F 104
Minimum ambient air temperature °C 1
Minimum ambient air temperature °F 33.8
Maximum compressed air inlet temperature °C 45
Maximum compressed air inlet temperature °F 113
Minimum compressed air inlet temperature °C 1
Minimum compressed air inlet temperature °F 33.8
