Instruction Book
95 9829 2115 69
7.3 Service Agreements
Atlas Copco Customer Centers have a range of service agreements to suit your
needs:
• An Inspection plan.
• A Preventive maintenance plan.
• A Total responsibility plan.
Contact your Customer Centre to agree on a tailor-made service agreement. It will ensure
optimum operational efficiency, minimize downtime and reduce the total life cycle costs.
7.4 Service Plan
A number of service operations are grouped (Level A, Level B, Level C). Each level
represents a number of service actions to be carried out at the time intervals programmed in
the Elektronikon regulator.
When reaching a level, a message will appear on the screen. After carrying out all service
actions, the interval timers are to be reset using the key "Reset" in menu "Service". Consult
your Atlas Copco Customer Center.
7.5 Filling Instructions
Initial filling
Models up to and including CD1100+ come pre-filled from the factory. There is
no need to fill dryer with additional desiccant at startup
Safety glasses, gloves and a dust mask must be worn during the filling
procedure as dust may be produced.
1. Make sure the dryer is empty and fit the bottom plugs or flanges. Apply thread tape to
tighten the plugs, use gaskets for the flanges.
2. Open the top plugs or flanges (1) for filling.
3. Fit a large funnel to the filling hole of one of the drying towers; the size of the narrow part
should be 1.5 in (35-40 mm).
4. Gently pour the correct amount of desiccant into the tower (see section Dryer data). Use a
vacuum cleaner to control dust escaping from the filling hole.
5. Repeat steps 3 and 4 for the other tower; the amounts of desiccant must be equal in
both towers.
6. Do not use any mechanical or pneumatic means for filling; this may destroy the
desiccant.
7. Refit the filling plugs or flanges. The dryer is now ready to be started (see section Start up
for starting instructions).
