Atlas Copco CD 480 User Manual

Instruction Book
27 9829 2115 69
Use the Scroll keys to select an icon.
Press the Enter key (2) to open the menu or press the Escape key (3) to return to the Main
screen.
3.6 Inputs Menu
Control panel
(1) Scroll keys
(2) Enter key
(3) Escape key
Menu icon Items
Function
To call up information regarding the actually measured data and the status of some inputs
such as the Blower Pressure.
Procedure
Starting from the main screen (see Main screen),
• Move the cursor to the action button Menu and press the Enter key. Following screen
