3.14 Modify parameters menu
Function
To modify a number of programmable settings:
• Parameters (see section Modifying parameters).
• Protections (see section Modifying protections).
• Service plan settings (see section Modifying service plan settings).
• Clock function settings (see section Modifying clock function settings).
• Configuration settings (see section Modifying configuration settings).
3.15 Modifying parameters
Control panel
Function
To modify a number of parameters. Consult the menu flow in section Control programs.
Procedure
Starting from the Main screen (see Main screen menu):
• Press the key ‘Menu’ (F1).
• Press the arrow down key (1) until ‘Modify Params’ is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• The first item ‘Parameters’ will be followed by a horizontal arrow.
• Press the tabulator key (2): the first item ‘Loading Press.’ and its setting will appear.
• Press the arrow down key (1) until the parameter to be modified is followed by a horizontal arrow.
Modifying the loading and unloading pressures
If desired, the operator can program two pressure bands (band 1 and band 2) with different loading and
unloading pressures. The settings for band 1 are indicated as ‘Loading Press.’ and ‘Unloading Press.’, the
settings for band 2 are indicated as ‘Loading Press.2’ and ‘Unloading Press.2’).
Example:
For pressure band 1:
• Loading pressure: 6.4 bar
• Unloading pressure: 7.0 bar
For pressure band 2
Instruction book
38 API603130
