Installation Manual 18 Document #: LTRT-83506
Mediant 1000
2.4 Cabling the Device
This section describes the cabling of the device, which includes the following:
Connecting to earth/ground (refer to 'Earthing (Grounding) the Device' on page 18)
Protective Earthing
The equipment is classified as Class I EN60950 and UL60950 and must be
earthed at all times. Therefore, before connecting the device to power and
communication interfaces (listed below), you must earth the device.
Connecting to the IP/Ethernet network (refer to ‘Connecting to IP Network’ on page 19)
(Option
al) Connecting the FXS/FXO interfaces (refer to 'Connecting to FXS/FXO
Interfaces' on page 20)
(Option
al) Connecting the analog Lifeline telephone (refer to 'Cabling to Analog Lifeline
Phone' on page 21)
(Option
al) Connecting the BRI ports (refer to 'Connecting to ISDN BRI Lines' on
page 22)
- applicable only to SIP
(Optional) Connecting the E1/T1 trunks (refer to 'Connecting to E1/T1 Trunks' on
page 23)
(Option
al) Connecting the E1/T1 trunks for PSTN Fallback (refer to 'Connecting to
E1/T1 Trunks for PSTN Fallback' on page 24)
(Option
al) Connecting the Dry Contact Relay Alarm System (refer to ‘Connecting to
Dry Contact Relay Alarm System’ on page 25)
(Option
al) Connecting to a PC for serial communication (refer to 'Connecting RS-232
Serial Interface to PC' on page 27)
Con
necting the device to the power supply (refer to 'Connecting to Power' on
page 28)
Once you ha
ve cabled and powered-up the device, the POWER LED on the front panel of
the Power Supply module is lit green. Any power supply malfunction results in the LED
being off (for a description of the LEDs, refer to 'Monitoring Front-Panel LEDs' on page 57).
Once you h
ave cabled the device, you can begin configuring the device (refer to
'Configuring the Device' on page 35).
