LOCATION OF EXTERNAL COMPONENTS
The following figures apply to both narrow versions (FL 960) and wide versions (FL 970).
Right unit
Ref.: Designation:
1 Extension cover
2 Top cover
3 Fixed glass
4 Reader cover
5 Cover without reader
6 Orientation and function pictogram
7 Moving obstacle
8 Panel for access to the mechanism(s)
9 DIRAS cells behind tinted Plexiglass
10 End panel
1
4
6
10
2 3
8
9
7
5
