COMMISSIONING
IMPORTANT: Check that the SW2 switch of the last bus CAN card is "ON".
( Wiring diagrams)
1. Turn on the main circuit breaker (Ch.3.6. , 18) to power up the equipment and close the extension
covers.
When power is applied, the obstacles will go through an opening and closing cycle to determine the
opening end positions of the equipment.
The function pictograms are blue.
2. Configure the lane via the Maintenance Interface (obstacle dimensions, opening speed, etc.) see
specific manual.
3. Perform several openings and closings using the available controls (reader, remote control, etc.) and
check the obstacle position in the open and closed positions.
4. Check that the obstacles open completely when an evacuation order is issued.
5. Pass through several times and check that the pictograms and buzzer operate properly.
6. Check that the optional equipment (monitoring panel, etc.) and customer-incorporated equipment
(reader, etc.) is operating correctly.
