When the equipment is powered up, the function pictograms flash red during start-up of the CPU.
This is followed by an initialization phase during which the pictograms turn blue and the obstacles move
into their end positions.
When the equipment is operational, the pictograms indicate the operating mode defined by the
direction of passage.
REMOVING THE TOP COVER
After powering up the equipment in accordance with Ch.0, remove the 4 screws + washers holding the
profile on the upper railing. Place the cover in a safe location.
REMOVING THE KINEMATIC PANEL
Start by opening the extension covers ( Ch.7.2. ) and switching off the equipment ( Ch.0).
Then remove the two screws holding the panel on the base frame.
4x
2x
