MODULIZER PRO DSP1224P

EDITB: Resonance: adjusts the quality/resonance of the filter.

EDITC: Depth: controls the modulation depth applied to the cut-off frequency.

EDITD: Speed: controls the LFO speed between 0.004 and 9.9 Hz for modes L1 and L2, or the

envelope follower speed for modes A1 and A2.

Jetstream Flanger

Originally, flanging effects were produced by two tape recorders synchronized to each other. Both

machines played back the same signals (e.g. a guitar solo). By applying just a little bit of pressure to

the flange of the supply reel of one tape recorder you can slow down the playback speed. The resulting

delay produces phase shifts which in turn lead to a cancellation of certain frequencies, which is called

comb-filter effect. Since the pressure applied to the reel is not constant, the canceled frequencies and

thus the sound spectrum are varying continuously. In todays age of digital technology you dont have to

use your fingers any longer. The MODULIZERPRO mixes the original signal with a delayed copy of the

signal. The resulting cancellations are varying as the delay time is being modulated from an LFO.

Depending on the maximum delay time and LFO frequency you can produce sometimes dramatic

sound effects which become increasingly metallic as the effect intensity is raised. The sound re-

sembles that of a flying jet plane (Jetstream). In addition to a positive feedback, the DSP1224P also

allows you to add negative feedback which results in a tube-like sound.

The parameters:

VARIATION: Speed: adjusts the LFO speed between 0.004 and 9.9 Hz.

EDITA: Delay: this parameter sets the maximum delay time (1-20 ms).

EDITB: Depth: adjusts the modulation depth.

EDITC: Feedback: controls the amount of effect signal that is fed back to the input.

EDITD: Bandlimit: this parameter enables you to filter the feedback path, which is useful for feedback

settings of up to 100%.

+ Tip: there is no limitation as to the range of instruments that can be processed with a flanging

effect. Check out vocal sounds too, but remember that less is often more!

Spatial Flanger

Includes an additional stereo effect giving the audio material more room acoustics information. The

parameters are the same as the jetstream flanger.

Ultra Chorus

Think of a string quartet with each musician playing the same notes. As a matter of fact, however,

musicians can never play exactly the same, which results in a sequence of slightly detuned and de-

layed signals. In a chorus, copies of the original signal are delayed by 20-40 ms, slightly detuned and

modulated by an LFO. The MODULIZERPRO features no less than 8 voices, which corresponds to a

group of 8 musicians playing simultaneously.

The parameters:

VARIATION: Speed: controls the LFO speed between 0.1 and 5 Hz.

EDITA: Delay: this parameter adjusts the delay time (1-80 ms).

EDITB: Depth: sets the modulation depth.

EDITC: Stereo Width: positions the individual voices on the stereo basis.

EDITD: Wideness: controls the effect width by detuning the individual voices against each other.

+ The Ultra Chorus widens the audio material, for example to enhance thin-texture keyboard

pads, give vocals more room acoustics information and guitar sounds a dreamy character.
