MODULIZER PRO DSP1224P
5.3 MIDI implementation
MIDI Implementation Chart
Function Transmitted Recognized Remarks
Basic
Channel
Default
Changed
OFF, 1 - 16
OFF, 1 - 16
OFF, 1 - 16
OFF, 1 - 16
memorized
Mode
Default
Messages
Altered
1,2,3,4
X
X
1,2,3,4
X
X
Note Number
True Voice
X
X
X
X
Velocity
Note ON
Note OFF
X
X
X
X
After Touch
Key´s
Ch´s
X
X
X
X
Pitch Bender X X
Control O 50 - 62 O 50 - 62 see add. Table
Progr.
Change True #
O (0-99)
1-100
O (0-99)
1-100
System Exclusive X X
System
Common
Song Pos
Song Sel
Tune
X
X
X
X
X
X
System
Real Time
Clock
Commands
X
X
X
X
Aux
Messages
Local ON/OFF
All notes OFF
Active Sense
Reset
X
X
X
X
X
X
X
X
Notes
O = YES, X = NO
Mode 1: OMNI ON, POLY
Mode 2: OMNI ON, MONO
Mode 3: OMNI OFF, POLY
Mode 4: OMNI OFF, MONO
Tab. 5.3: MIDI implementation chart
Parameter Name Display
Range
Midi-
Controller
Controller
Range LEDs
Couple Left Right IN on IN off
Effect 1..24 50 0..23
Variation dep. on effect* 51 0..xxx
Edit A " 52 "
Edit B " 53 "
Edit C " 54 "
Edit D " 55 "
Modulation Controller 0..127 56 0..127
EQ Low -16..16 57 0..32
EQ High -16..16 58 0..32
Mix 0..100 59 0..100
Store 1..100 60 0..99
In/Out 61 0=Out, 1=In 1 0
External/Internal Mix --/(Mix) "--"=Ext 62 0=Ext, 1= Int
* nF = no function
Tab. 5.4: Controller functions with MIDI
