Behringer MODULIZER PRO DSP1224P User Manual

21
MODULIZER PRO DSP1224P
Display Mode
0 Program changes are not transmitted
1 Program changes are received but not transmitted
2 Program changes are transmitted but not received
3 Program changes are transmitted and received
Tab. 2.2: Program change settings
The fifth page of the MIDI menu shows the store enable flag represented by a capital S in the display. The
value 0 disables the reception of controller #60, and therefore protects the user presets from being modified
via MIDI. Accordingly, the value 1 enables MIDI controller #60 so that you can modify or replace presets with
a remote MIDI device or a sequencer. In this case the actual settings will be stored directly to the location that
corresponds to the controller value.
+ Attention! Since the store enable mode allows you to access memory locations directly via
MIDI, it is possible that stored presets will be replaced or altered if controller #60 messages are
sent on the same MIDI channel. The purpose of this mode is to facilitate MIDI backup and
restore operations without express confirmation at the MODULIZERPRO. It is therefore recom-
mended to disable (flag=0) this mode as soon as the intended data transfer has ended. This is
done automatically when you switch off the MODULIZERPRO.
On the sixth, and presently the last, page you can access the System Exclusive functions. This is indicated
by a d (for dump) in the display. To the left of this d a number is displayed:
- 0 means that no SYSEX data will be sent or accepted.
- 1 will enable the MODULIZER PRO to receive data. When STORE is pressed the unit will wait for data, this
is shown by flashing dots (LEDs) in the display. The MIDI button LED flashes signaling that SYSEX data is
being received.
- 2 will enable the MODULIZER PRO to send a bulk dump. Start your sequencer and press STORE on the
DSP1224 to start the transmission.
To load these settings again, select 1, press STORE and start your sequencer. If you press IN/OUT again, you
will leave the MIDI setup. You can at all times press any other key to leave the MIDI setup directly.
If you press the IN/OUT key again on the sixth page, the MODULIZERPRO quits MIDI setup mode.
+ During a bulk dump all audio functions of the MODULIZERPRO will be deactivated.
The full-featured MIDI implementation of the MODULIZERPRO allows for easily integrating the MODULIZERPRO
into any MIDI system.
s MIDI IN
Any MIDI data sent to the MODULIZERPRO (sequencer, MIDI footswitch, etc.) is received via the MIDI IN jack.
For example, when you wish to use the MODULIZERPRO as an effects devices for your guitar rack, you can
connect the MIDI IN jack to a MIDI footswitch that allows for selecting program presets. If your rack includes
another MIDI effects devices (e.g. a multi-effects processor), the data sent from the MIDI footswitch can be
routed via the MODULIZERPRO's MIDI THRU jack to your multi-effects processor.
s MIDI THRU
The MIDI THRU jack is used to loop through incoming MIDI data, i.e. any control data received at the MIDI IN
of the MODULIZERPRO can be transmitted via the MIDI THRU jack to other MIDI devices/instruments.
s MIDI OUT
The MIDI OUT jack allows for transmitting MIDI data that originate from the MODULIZERPRO.
2.5.1 Modulation-controller
It is even possible to modulate some of the LFO effects manually or via MIDI. You can access the modulation
value pressing EDIT A and EDITC at the same time while LFO speed is set to zero. The modulation status can
now be controlled with the jog wheel; i.e. you can set and change the delay used by the MODULIZER PRO
manually to create a Doppler effect. If you try to change the modulation parameter while the LFO speed is not
zero the display will show a dot in the lower right corner signaling that no changes can be made.
2. OPERATION
