SG-150-1 29
10.4 Status data
10.4.1 Status – alarm
The group contains information about current state of alarms
Name
Possible
values
Default
Description
Modbus
type & addr
Number of active
alarms
unit None
scale 1
uint16
-
Number of active alarms
IR 11100
Number of listed
alarms that has not
yet been cleared
unit None
scale 1
uint16
-
Number of listed alarms that has
not yet been cleared
IR 11101
Highest state of any
listed alarm
unit None
scale 1
uint8
-
Highest state of any listed alarm
(0=Clear, 1=Inactive, 2=Active,
3=Set)
IR 11102
Highest severity level
of any active alarm
unit None
scale 1
uint8
-
Highest severity level of any
active alarm
(0=None, 1=Log, 2=Event,
4=Info, 8=Warning, 16=Critical,
32=Fault)
IR 11103
Locked
unit None
scale 1
uint8
-
If locked, the CM-SW-01 is
waiting for external reset
command or restart
(0=No, 1=Yes)
IR 11104
Reset level required to
clear any active alarm
unit None
scale 1
uint8
-
Reset level required to clear any
active alarm
(0=NA, 1=Auto, 2=Timer,
3=Extern, 4=Restart)
IR 11105
Code of highest
ranked alarm
(AlarmStatus.Alarm1)
unit None
scale 1
uint16
-
Code of highest ranked alarm
IR 11201
Code of second
highest ranked alarm
(AlarmStatus.Alarm2)
unit None
scale 1
uint16
-
Code of second highest ranked
alarm
IR 11202
AlarmStatus.Alarm3
unit None
scale 1
uint16
-
IR 11203
AlarmStatus.Alarm4
unit None
scale 1
uint16
-
IR 11204
AlarmStatus.Alarm5
unit None
scale 1
uint16
-
IR 11205
AlarmStatus.Alarm6
unit None
scale 1
uint16
-
IR 11206
AlarmStatus.Alarm7
unit None
scale 1
uint16
-
IR 11207
