Bitzer CM-SW-01 User Manual

36 SG-150-1
Name
Possible
values
Default
Description
Modbus
type & addr
Hour and Minute
0 - 5947
scale 1
uint16
0
Hour and Minute
HR 20102
Millisecond
0 ms -
59999 ms
scale 1
uint16
0 ms
Millisecond
HR 20103
Serial Control Source
unit None
scale 1
uint8
-
Serial Control Source
(0=None, 1=COM1 (MODBUS))
IR 20300
Serial Control Timeout
Function
unit None
scale 1
uint8
-
Serial Control Timeout Function
(0=None, 1=Stop, 2=Fault)
IR 20301
Serial Control Timeout
Time
unit s
scale 1
uint16
-
Serial Control Timeout Time
IR 20302
10.5.2 Configuration – compressor
The group contains configuration information for the compressor
Name
Possible
values
Default
Description
Modbus
type & addr
Refrigerant selection
unit None
scale 1
uint8
-
Refrigerant selection
(0=NONE, 8=R717)
IR 22100
Dedicated OEM
functionality selection
unit None
scale 1
uint8
-
Dedicated OEM functionality
selection
(0=NONE)
IR 22200
Mains supply voltage
specification (single
phase)
unit V
scale 1
uint16
-
Mains supply voltage
specification (single phase)
IR 22300
10.5.3 Configuration – COM1
The group contains information for the serial communication
Name
Possible
values
Default
Description
Modbus
type & addr
COM1 Address
1 - 247
scale 1
uint8
48
Device address for Modbus
connection
HR 65409
COM1 Baudrate
1 - 132
scale 1
uint8
2
Communication speed
(1=9600, 2=19200, 3=115200,
129=300, 130=1200, 131=4800,
132=38400)
HR 65410
