Bitzer CM-SW-01 User Manual

32 SG-150-1
Alarm
number
Index
number
Description
8203
104
Output Current: Oil Heater High
8204
105
Output Current: Additional fan (Head fan) Low
8205
106
Output Current: Head Fan High
8206
107
Output Current: CR-1 Low
8207
108
Output Current: CR-1 High
8208
109
Output Current: CR-2 Low
8209
110
Output Current: CR-2 High
8210
111
Output Current: CR-3 Low
8211
112
Output Current: CR-3 High
8212
113
Output Current: Unloader Low
8213
114
Output Current: Unloader High
8214
115
Output Current: Oil Inj Low
8215
116
Output Current: Oil Inj High
8216
117
Output Current: Liquid Inj Low
8217
118
Output Current: Liquid Inj High
8218
140
Output Current: HW Trip
8580
126
Slider: Vi Position Control
8581
127
Slider: CR Position Control
8582
128
Slider: Gap between Vi and CR
8583
129
Slider: Gap between Zero and Vi
10.4.2 Status – compressor
The group contains status information for the compressor
Name
Possible
values
Default
Description
Modbus
type & addr
Suction Pressure
unit bar(a)
scale 100
sint16
-
Suction Pressure
IR 12001
Discharge Pressure
unit bar(a)
scale 100
sint16
-
Discharge Pressure
IR 12002
Evaporating
Temperature (SST)
unit °C
scale 10
sint16
-
Calculated saturated suction
temperature (SST)
IR 12003
Condensing
Temperature (SDT)
unit °C
scale 10
sint16
-
Calculated saturated discharge
temperature (SDT)
IR 12004
Envelope Status
unit None
scale 1
uint8
-
Envelope operation status
(0=Stopped, 1=Starting,
2=Running, 3=Stopping,
4=Warning - inside envelope,
5=Critical - outside envelope,
6=Fault)
IR 12005
Envelope Zone
unit None
scale 1
uint8
-
Actual zone of operation
(0=Inside, 1=SST Low, SDT Low,
2=SST Low, 3=SST Low, SDT
IR 12006
