10.4.3 Status – motor
The group contains status information for the motor
Name
Possible
values
Default
Description
Modbus
type & addr
Motor overheat
thermistor resistance
(PTC)
unit Ohm
scale 1
uint16
-
Motor overheat thermistor
resistance (PTC)
1)
IR 13001
Estimated motor
power consumption
unit kW
scale 10
uint16
-
Estimated motor power
consumption
1)
IR 13002
Motor drive frequency
(speed)
unit Hz
scale 10
uint16
-
Motor drive frequency (speed)
1)
IR 13003
Motor phase detection
state
unit None
scale 1
uint8
-
Motor phase detection state
1)
(0=STOP, 1=RUN, 2=REVERSE,
3=L1_LOSS, 4=L2_LOSS,
5=L3_LOSS, 6=L1_L3_LOSS,
7=FREQ_LOW, 8=FREQ_HIGH,
9=ERROR)
IR 13004
Motor phase current
unit A
scale 100
sint16
-
Motor phase current
1)
IR 13005
Motor start contactor
1
unit None
scale 1
uint8
-
Motor start contactor 1
(0=Off, 1=On)
IR 13006
Motor start contactor
2
unit None
scale 1
uint8
-
Motor start contactor 2
(0=Off, 1=On)
IR 13007
Note 1: For future compressor versions
10.4.4 Status – device
The group contains operating state for the CM-SW-01
Name
Possible
values
Default
Description
Modbus
type & addr
System operating
state
unit None
scale 1
uint8
-
System operating state
(0=CONFIG, 1=INPUT,
2=STARTUP, 3=READY,
4=SUSPEND, 5=SERVICE,
6=PRODUCTION)
IR 14000
