Studs 4 are engaged in grom-
mets 3.
Install screw 1.
Calibrating ASC ( 60).
Light source
Replacing bulbs for low-
beam headlight and high-
beam headlight
Make sure the ground is level
and firm and place the Maxi-
Scooter on its stand.
Switch off the ignition.
Remove the right side panel to
replace the bulb for the low-
beam headlight.
Remove the left side panel to
replace the bulb for the high-
beam headlight.
The bulbs have to be replaced
from below. Removing the side
panels improves orientation.
Remove cover 1 to replace the
bulb for the high-beam head-
light.
Remove cover 2 to replace the
bulb for the low-beam head-
light.
Disconnect plug 3.
Disengage spring clip 4 from
the latches and swing it up.
Remove bulb 5.
8
118
z
Maintenance
