Engine
Location of engine number Crankcase, left, below alternator
Engine type 652EA
Engine design Water-cooled 2-cylinder four-stroke with four
valves per cylinder, valve actuation by cam fol-
lowers, two overhead camshafts and dry sump
lubrication
Displacement 647 cm
3
Cylinder bore 79 mm
Piston stroke 66 mm
Compression ratio 11.6:1
Nominal output 44 kW, at engine speed: 7500 min
-1
with power reduction to 35 kW
OE
35 kW, at engine speed: 7500 min
-1
Torque 63 Nm, at engine speed: 6000 min
-1
with power reduction to 35 kW
OE
54 Nm, at engine speed: 4250 min
-1
Maximum engine speed max 8500 min
-1
Idle speed 1250 min
-1
, Engine at regular operating tempera-
ture
Exhaust emissions standard Euro4
11
150
z
Technical data
