Turn signal in exterior mirror
The turn signals in the exterior mirrors feature
LED technology. In the case of a malfunction,
contact a dealer's service center or another
qualified service center or repair shop.
Tail lights, bulb replacement
Overview
1 Turn signal
2 Outer brake lights
3 Inside brake light
4 Reversing light
5 Rear light
Bulb replacement
General information
Follow the safety information, refer to page 241.
Reversing light: 21-watt bulb, W21W.
The turn signals, brake lights, and rear lights fea‐
ture LED technology. In the case of a malfunc‐
tion, contact a dealer's service center or another
qualified service center or repair shop.
Removing the tail light
1. Opening trunk lid.
2. Open the two covers on the tail light.
3. With the handle of the screwdriver from the
onboard vehicle tool kit, loosen and remove
the nuts on the two fasteners. Make sure that
the nuts do not drop into the bumper area. In
addition to the two outer fasteners, there is
another inner fastener.
4. Hold the grip rail in one hand, arrow 1, and
brace against the outside with your other
hand, arrow 2. Carefully pry out the tail light,
arrow 3, until the rubber mount releases from
the inner fastener.
5. Remove the plug from the bulb holder.
Seite 242
MOBILITY
Replacing components
242
Online Edition for Part no. 01402720665 - II/19
