BMW R 1200RT 2015 User Manual

Locking up of the front wheel
is prevented by BMW Motorrad
Integral ABS.
Descending mountain
passes
WARNING
Braking only with the rear-
wheel brake when descend-
ing mountain passes.
Loss of braking action. Destruc-
tion of the brakes caused by
overheating.
Use both front and rear brakes,
and make use of the engine's
braking effect as well.
Wet, soiled brakes
Moisture and dirt on the brake
rotors and the brake pads result
in a decrease in the braking ac-
tion.
Delayed or poorer braking action
must be expected in the follow-
ing situations:
When driving in the rain and
through puddles.
After washing the vehicle.
When driving on roads spread
with salt.
After working on the brakes
due to oil or grease residues.
When driving on soiled roads
or offroad.
WARNING
Moisture and dirt.
Poorer braking action.
Brake until brakes are dry or
clean; clean if necessary.
Brake early until the full braking
action is available again.
Parking your
motorcycle
Side stand
Switch off engine.
ATTENTION
Poor ground conditions in
area of stand.
Component damage caused by
tipping over.
Always check that the ground
under the stand is level and
firm.
ATTENTION
Loading of the side stand
with additional weight.
Component damage cause by
tipping over.
Do not sit on the motorcycle
when it is parked on the side
stands.
5
98
z Riding
ProCarManuals.com

BMW R 1200RT 2015 Specifications

General

Displacement	1170 cc
Torque	125 Nm at 6, 500 rpm
Curb Weight	274 kg
Fuel System	Electronic fuel injection
Cooling System	Air/liquid-cooled
Final Drive	Shaft drive
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
ABS	Standard
Power	125 hp at 7, 750 rpm
Transmission	6-speed
Fuel Capacity	25 liters
Seat Height	805/825 mm (adjustable)
Front Suspension	Telelever fork
Rear Suspension	Paralever swingarm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 276 mm disc, 2-piston caliper
Engine Type	Air/liquid-cooled, four-stroke, flat twin
