The tire pressures are
shown adjusted for tem-
perature on the multifunction
display and are always relative
to the following tire air temper-
ature:
68 °F (20 °C)
Tire pressure gages at gas sta-
tions do not make any adjust-
ment for the air temperature,
the tire pressure indicated de-
pends on the temperature of the
air in the tire. As a result, in most
cases the values displayed there
do not match the values shown
in the multifunction display.
Adjusting inflation
pressure
Compare the TPC value in the
multifunction display with the
value on the back cover of the
Rider's Manual. The difference
between the two values must be
compensated with the air pres-
sure tester at the filling station.
Example
According to the Rider's Man-
ual, the tire pressure should
be as follows:
36.3 psi (2.5 bar)
The multifunction display
shows the following figure:
33.4 psi (2.3 bar)
The shortfall is thus:
2.9 psi (0.2 bar)
The tester at the filling station
shows:
34.8 psi (2.4 bar)
To obtain the correct tire pres-
sure, that has to be increased
to the following figure:
37.7 psi (2.6 bar)
ESA
with Dynamic ESA
OE
Adjustment options
Using the Dynamic ESA elec-
tronic suspension adjustment
system you can easily adjust your
motorcycle to the load being car-
ried.
Using leveling sensors, Dynamic
ESA detects movements of the
running gear and responds to
them by adjusting the damper
valves. As a result, the running
gear is adjusted to the conditions
of the ground.
In addition, the damping char-
acteristic can be made harder
(HARD) or softer (SOFT) relative
to the normal setting (NORMAL).
6
114
z
Technology in detail
