as to ensure the adjustment is
even.
Mirrors
Adjust mirrors
Move mirror into the desired
position by pressing lightly on
the edge of the glass.
Windshield
Adjust windshield
Switch on ignition.
When you pull away the wind-
screen automatically returns to
the position it was in before the
ignition was switched off.
Press button 1 at top to raise
windshield.
Press button 1 at bottom to
lower windshield.
Switch off ignition.
The windscreen automatically
moves to the bottom limit posi-
tion.
If the windscreen encounters
resistance before it reaches
its limit position the pressure-
sensitive finger guard system
goes active. The windscreen
is stopped and raised slightly.
After a delay of a few seconds
the windscreen again attempts
to move to the bottom limit
position.
There is no guarantee that the
pressure-sensitive finger guard
system will function correctly if a
windscreen that does not have
BMW Motorrad approval is in-
stalled.
Under these circumstances:
Before switching off the igni-
tion always check that there is
nothing to obstruct movement
of the windscreen.
4
76
z Operation
ProCarManuals.com

BMW R 1200RT 2015 Specifications

General

Displacement	1170 cc
Torque	125 Nm at 6, 500 rpm
Curb Weight	274 kg
Fuel System	Electronic fuel injection
Cooling System	Air/liquid-cooled
Final Drive	Shaft drive
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
ABS	Standard
Power	125 hp at 7, 750 rpm
Transmission	6-speed
Fuel Capacity	25 liters
Seat Height	805/825 mm (adjustable)
Front Suspension	Telelever fork
Rear Suspension	Paralever swingarm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 276 mm disc, 2-piston caliper
Engine Type	Air/liquid-cooled, four-stroke, flat twin
