BMW R 1200RT 2015 User Manual

To avoid damaging the cover
and the mounts, lift off cover at
the positions 3.
WARNING
Uncoordinated settings of
spring preload and spring
strut damping.
Poorer handling.
Adjust damping characteristic
to changed spring preload.
To raise the spring preload,
turn the adjustment knob 1
clockwise using the special
tool 2 (onboard tool kit).
To reduce the spring preload,
turn the adjustment knob 1
counterclockwise using the
tool 2.
Basic setting of spring
preload, rear
without Dynamic ESA
OE
Turn adjuster wheel counter-
clockwise as far as possible.
(One-up without load)
Turn adjuster wheel as far
as possible counterclock-
wise, then 10 turns clockwise.
(One-up with load)
Turn adjuster wheel clockwise
as far as possible. (Two-up
and load)
Insert cover in mount 2 and
press it into mounts 1.
Damping
Setting
The damping must be adjusted
to the road conditions and the
spring preload.
A rough road surface requires
softer damping than a smooth
road surface.
An increase in spring preload
requires firmer damping, a re-
duction in spring preload re-
quires softer damping.
4
68
z Operation
ProCarManuals.com

BMW R 1200RT 2015 Specifications

General

Displacement	1170 cc
Torque	125 Nm at 6, 500 rpm
Curb Weight	274 kg
Fuel System	Electronic fuel injection
Cooling System	Air/liquid-cooled
Final Drive	Shaft drive
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
ABS	Standard
Power	125 hp at 7, 750 rpm
Transmission	6-speed
Fuel Capacity	25 liters
Seat Height	805/825 mm (adjustable)
Front Suspension	Telelever fork
Rear Suspension	Paralever swingarm
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 276 mm disc, 2-piston caliper
Engine Type	Air/liquid-cooled, four-stroke, flat twin
