Bosch Solution 6000-IP User Manual

17Bosch Security Systems 10/22 BLCC615U
Solution 6000-IP User Guide
Ur1 John Smith
Ur2 Debbie Smith
Ur3 User 3 Name
Press  OK or MENU
The keypad will display;
Press OK to delete
Fingerprint for Ur1
User 1 Name
Press OK or MENU
3. When prompted press the [OK] key to confirm
fingerprint deletion.
Access > Fingerprint >
Fingerprint Status
MENU 1-8-2
This menu allows a master user the ability to identify a
fingerprint which has been programmed into the system.
Only fingerprints that have been assigned to the same
area(s) as the Master user can be identified.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [1] + [8] + [2].
The system will prompt you to present the finger to
the reader.
Position Finger at
Fp9
Press OK or MENU
2. Once the presented the system will display the user
assigned to the fingerprint.
Finger belongs to Ur1
John Smith
Press OK or MENU
Areas
The control panel has the ability to be partitioned up to
8 individual areas. This section outlines various commands
that control individual areas.
Areas > Commands >
Area Status
MENU 2-0-0
This menu allows users the ability view the area status of
the current area or the status of a different area. This menu
is only available via a keypad who’s corresponding area is
turned off.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [0].
A list of available areas will display on the keypad.
A1 Main Oce
A2 Production
A3 Warehouse
Press  OK or MENU
2. Use the [] and [] keys to select the area that you
want to view the status information, then press
[OK] to select. Alternatively, you can enter the area
number, then press [OK]. The keypad will display
the area status information.
Main Oce A1
Disarmed
Press OK or MENU
If the area is turned All On, the keypad will display
the following. Note in this example 1 zone has been
bypassed.
Main Oce A1
Armed All On
1 Zones Bypassed
Press OK or MENU
If the area is turned Part On, the keypad will display:
Main Oce A1
Armed Part On
Press OK or MENU
3. To exit, press [OK].
Areas > Commands >
Turn Area On/Off
MENU 2-0-1
This menu allows you to turn an area All On or off.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [1].
A list of different areas will display on the keypad.
A1 Reception Area
A2 Sales Dept 
A3 Administration Dept
Press  OK or MENU
If an area has already been turned All On or Part On,
a ‘tick’ () will be displayed on the right side of the
name description (see A2 Sales Dept above).
2. Use the [] and [] keys to select the area that you
want to turn on or off, then press [OK] to select.
Alternatively, you can enter the area number you
want to turn on or off, then press [OK].
