Bosch Solution 6000-IP User Manual

Solution 6000-IP
18 Bosch Security Systems 10/22 BLCC615U
User Guide
Areas > Commands >
Turn All Areas On
MENU 2-0-2
This menu allows you to turn on all areas that your PIN
has been assigned to at the same time All On. The keypad
display below shows the area icons 1 through to 8.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [2].
The keypad will display the exit time bar to prompt
you to exit all areas. You should leave all areas now.
Area 1 Name
EXIT
NOW
When exit time has expired, the keypad will display
that all areas are turned All On (Armed).
Area 1 Name
ARMED
Fri,Aug,13 5:34 pm
i
Note
Area icons will only display if programmed to
do so by your security installer.
Areas > Commands >
Turn All Areas Off
MENU 2-0-3
This menu allows you to turn off all areas that your PIN has
been assigned to at the same time. However, this menu
requires at least one area that has a keypad assigned to it to
be disarmed before you can access this command.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [3].
Areas > Commands >
Move To Area
MENU 2-0-4
This menu allows you to operate multiple areas from the
same keypad when the system has been partitioned.
Before operating a different area, you will need to move
the keypad to the area that you want to operate.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [4].
A list of different areas will display on the keypad.
A1 Reception Area
A2 Sales Dept
A3 Administration Dept
Press  OK or MENU
2. Use the [] and [] keys to select the area that you
want to move the keypad display to, then press
[OK] to select. Alternatively, you can enter the area
number that you want to move the keypad display
to, then press [OK].
Areas > Commands >
Chime On/Off
MENU 2-0-5
Chime mode allows you to monitor a zone (or group
of zones) and to sound the keypad buzzer or activate a
programmable output when the a zone programmed for
chime is open and the system is in the disarmed state. This
can be useful when you need to monitor the front or back
entrance to the premises.
This menu allows a user to turn chime mode on or off.
Only keypads programmed to sound the chime tone will
be heard when a zone programmed for chime is faulted.
The master user can set which zone are to be chime zones
via MENU 3-0-3. If no zones are programmed for chime
then chime mode will not activate.
Enter programming mode (PIN + MENU) then,
1. Enter [MENU] + [2] + [0] + [5].
A list of different areas will display on the keypad.
A1 Reception Area 
A2 Sales Dept
A3 Administration Dept
Press  OK or MENU
2. Use the [] and [] keys to select the area that you
want to turn chime mode on or off, then press [OK]
to select. Alternatively, you can enter the area
number that you want to turn chime mode on or
off, then press [OK]. The keypad will display the
following when chime mode is turned off:
Reception Area A1
Chime is OFF.
To turn ON, Press ON.
To Go Back Press OK
The keypad will display the following when chime
mode is turned on:
Reception Area A1
Chime is ON.
To turn OFF, Press OFF.
To Go Back Press OK
