MAIN PART LIST

F1 Subwoofer (refer to Figure 4)

Item

Number

Description Part Numbe

Qty. Note

1 WOOFER, 10 INCH, BASS, SVCE 625261-001S 2

2 FOOT, BOTTOM, BASS, SVCE 625289-011S 2

3 GRILLE, SUB, SVCE 625269-011S 1

4 STAND, PLASTIC, SVCE 716548-011S 1

5 PCB ASSY, DSP – I/O, BASS, SVCE 716571-001S 1 1

6 SCREW, FOOT, M4x25 721717-001S 2

7 SCREW, M4, GRILLE, BASS 625290-011S 2

8 ASSEMBLY, SUB, LED, SVCE 722875-001S 1

9 POWER SUPPLY, SUB, SVCE

(PCB ASSY ONLY)

628476-001S 1 1

POWER SUPPLY/AMP SUBASSY, SVC

(INCLUDES MOUNTING PLATE, GASKET,

AC INLET AND POWER SWITCH)

718294-001S

- SCREW, WOOFER, M4x25 721717-001S 16

- WIRE HARNESS, WOOFER, LONG, SVC 745190-001S 1

- WIRE HARNESS, WOOFER, SHORT, SVC 745191-001S 1

- WIRE HARNESS, DSP, SVC 745192-001S 1

- SMPS, COVER, BASS, SVCE 715782-011S 1

- KNOB, VOLUME, SERV 720516-011S 2

- SLIDE, SWITCH CAP, SERV 720517-011S 3

- LIGHT GUIDE, LED, /I/O, SERV 720518-001S 3

- LIGHTGUIDE, LED, SUB, SVCE 722863-001S 1

- LENS, LED, SUB 722860-001S 1

- POWER SWITCH (AC) 317373-000S 1 3

- GASKET, I/0 PANEL, SVC 728370-011S 1

- SMPS, GASKET, BASS, SVC 728344-011S 1

- PANEL, I/O, BASS, SVC 625278-011S 1

- AC SWITCH, SHRINK TUBE 753068-001S 1 3

- AC INLET, SHRINK TUBE 753069-001S 1 3
