Bose F1 812 Service Manual

51
ELECTRICAL PART LIST
Resistors
Reference
Designator
Description
V
endor Part
Number
Note
R1 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R2 CHIP, RES, 100 OHM, 1/4, W, 1%, TF, 1206, DALE,
CRCW12061000FRT, E3
QCF041010-1000
R3 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R4 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R5 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R6 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R7 CHIP, RES, 100 OHM, 1/4, W, 1%, TF, 1206, DALE,
CRCW12061000FRT, E3
QCF041010-1000
R8 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R9 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R10 CHIP, RES, 100 OHM, 1/4, W, 1%, TF, 1206, DALE,
CRCW12061000FRT, E3
QCF041010-1000
R11 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R12 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R13 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R14 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R15 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R16 CHIP, RES, 100 OHM, 1/4, W, 1%, TF, 1206, DALE,
CRCW12061000FRT, E3
QCF041010-1000
R17 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R18 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R19 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R20 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R21 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R22 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R23 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R24 CHIP, RES, 51 OHM, 1%, 1/4W, 1206 QCF041010-5109
R25 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R26 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R27 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R28 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R29 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R30 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R31 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R32 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R33 CHIP, RES, 9.1K OHM, 1/8W, 1%, 0805 QCF081020-9101
R34 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R35 CHIP, RES, 9.1K OHM, 1/8W, 1%, 0805 QCF081020-9101
R36 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R37 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R38 CHIP, RES, 51 OHM, 1%, 1/4W, 1206 QCF041010-5109
R39 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R40 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R41 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R42 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R43 CHIP, RES, 51 OHM, 1%, 1/4W, 1206 QCF041010-5109
R44 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R45 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R46 CHIP, RES, 51 OHM, 1%, 1/4W, 1206 QCF041010-5109
R47 GP, CHIP, RES, 649 OHM, 1/10W, 1%, 0603 QCF011030-6490
R48 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
F1 Subwoofer Input-Output / DSP PCB Assembly
