ELECTRICAL PART LIST
Miscellaneous (continued)
SMPS / Power Amplifier PCB Assembly
Resistors
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Qty. Note
- SHRINKING TUBE, DIA=35, L=40mm,
BLK,SA2420, SANYO (Used on subwoofer version)
DTB135000-0400 1 3
- Silicon, Insulator, For, L30.7xW1 HISA00021-0001 1
- SILICON, INSULATOR, L105*W26.5*T0.2 HISA00012-0001 1
- SILICON, INSULATOR, L80*W26.5*T0.2, 5 HISA00013-0001 1
- SILICON, INSULATOR, L80*W26.5*T0.2, 6 HISA00014-0001 1
- Spacer, Support, PG:H-14, Nylon, 66(UL),
H14XM3XW5.5
DSS100095-0001 1
- Star Washer, OD6.0xID3.3xH0.4x NICKEL PLA HWSA56433-1050 18
- STRAND, WIRE, UL1617, 18AWG, BLUE, 100mm,
A/B=STR, 5MM (Used on subwoofer version)
VWR0317BB-
0100
1
- STRAND, WIRE, UL1617, 18AWG, BROWN,
100mm, A/B=STR, 5MM (Used on subwoofer
version)
VWR0312BB-
0100
1
- Subwoofer AMP Panel, Aluminum, 1050, bl,
L261xW146xH14xT3 (Used on subwoofer version)
GALA00625-0001 1
- Support, Heatsink, PC, UL 94, V-0,L50xW25xH3 BPSA02080-0001 2
- Transistor Holder, PBT, TR-04H-
PBW,L13xW10.1xH3.6
DHU201006-0001 12
- Transistor Holder, PG:TR-03P-PBT, UL, 94V-
0,L14XW13XH4.8
DHU201005-0001 1
- U Heatsink, AL6061, Temper-O, Nat,
L50.4xW27xH31.5
GALA00605-0001 1
Reference
Designator
Description
V
endor Part
Number
Note
R1 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R2 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R3 GP, CHIP, RES, 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R4 CHIP, RES, 270 OHM, 1/10W, 1%, 0603 QCF011030-2700
R5 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R6 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R7 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R8 CHIP, RES, 1.1K OHM, 1%, 1/10W, 0603 QCF011030-1101
R9 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R10 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R11 CHIP, RES, 1.1K OHM, 1%, 1/10W, 0603 QCF011030-1101
R12 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R13 CHIP, RES, 20 OHM, 1%, 1/8W, 0805 QCF081020-2009
R14 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R15 CHIP, RES, 20 OHM, 1%, 1/8W, 0805 QCF081020-2009
R16 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R17 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R18 GP, CHIP, RES, 150 OHM, 1%, 1/10W, 0603 QCF011030-1500
R19 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R20 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R21 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R22 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
