Bose L1 Pro8 Service Manual

10
Main Part List
L1 Pro8 Power Stand (see Figure 2)
Item
Number
Description Bose Material
Number
Vendor Part
Number
Notes
1 WASHER, OD12.7XID8.5XT2.0 - T181200000740
2 WASHER, OD16XID8.1XT1.1 - T181200000590
3 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031200
4 BRACKET, ANTENNA - T100424500100
5 SCREW, T3.5XL10 - T15335101F610
6 SILICON FOAM, 25 DEGREE, TOP - T180200015760
7 SCREW, T4XL15 - T15001111F610
8 AMP, MAIN PCBA, ASSY - T910000075360
9 SCREW, M3XL16 - T151301630610
10 LINT, ADHESIVE, BLACK, 3M9448A K - T180000008640
11 BRACKET, SECC - T130207500100
12 NON WOVEN, ADHESIVE, BLACK, 3M
9448A
- T182900003120
13 SOLDER LUG, OD8.0XID4.1XL56 - T690300045600
14 ENCLOSURE, RIGHT - T100422700100
15 BRACKET, WOOD, MDF, E1, BLACK - T180400000990
16 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031080
17 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500031040
18 SCREW, T4XL20 - T15340201F600
19 BOTTOM, BLACK - T100423000100
20 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031170
21 PC SHEET, BOTTOM, LEFT 843440-0110 T180700009360
22 PC SHEET, BOTTOM, RIGHT 843439-0110 T180700009370
23 INLAY, BOTTOM, BACK 860705-0110 T180700009790
24 PC SHEET, BOTTOM - T180700009560 3
25 RUBBER FEET, BOTTOM, LEFT - T180200016510
26 RUBBER FEET, BOTTOM, RIGHT - T180200016520
27 PORT, BLACK - T100422800100
28 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031180
29 CABLE, WF, 4PIN - T641700168600
30 SILICON FOAM, 25 DEGREE, BOTTOM - T180200015770
31 WOOFER, 20X340mm 829930-0010 T911600011280 3
32 NON WOVEN, ADHESIVE, BLACK, 3M
9448A
- T182900003190
33 NON WOVEN, ADHESIVE, BLACK, 3M
9448A
- T182900003200
