Bose L1 Pro8 Service Manual

16
Main Part List
L1 Pro8 Array Speaker (see Figure 4)
Item
Number
Description Bose Material
Number
Vendor Part
Number
Notes
1 BAFFLE, ARRAY - T100423500100
2 DRIVER, 2 IN 812886-0010 T911600010920 3
3 SCREW, T3XL10 - T15330101F611
4 CABLE, ARRAY, 6PIN - T641700169100
5 CABLE, TW, CONNECT SINGLE - T641700168700
6 SILICON FOAM, 25 DEGREE - T180200015730
7 SILICON FOAM, 25 DEGREE - T180200015720
8 WADDING, FR-W0025, WHITE - T182700002490
9 ENCLOSURE CURVEN, ARRAY - T100423600100
10 SCREW, T3XL15 - T15330151F610
11 NON WOVEN, ADHESIVE, BLACK,
DS11 K
- T182900003260
12 NON WOVEN, ADHESIVE, BLACK,
DS11 K
- T182900003270
13 EVA, 38 DEGREE, ADHESIVE,
BLACK, DS11 K
- T180500032600
14 NON WOVEN, ADHESIVE, BLACK,
DS11 K
- T180500032600
15 NON WOVEN, ADHESIVE, BLACK,
DS11 K
- T182900003220
16 ENDCAP, ARRAY, LOWER 833733-0110 T100424400100
17 SCREW, T3XL12 - T153301230610-02
18 WASHER, SUS304 - T181200001410
19 TAPE, DOUBLE, DX6930 - T180000008760
20 LOGO, ARRAY - T100424600100
21 GRILLE ASSY, ARRAY, SVCE
(INCLUDES BOSE LOGO)
861202-011S T130207600100
22 PE FOAM, ADHESIVE, BLACK, DS11
K
- T180500031070
23 ENDCAP (TOP) 826315-0110 T100424700100
24 PC SHEET, PRODUCT LABEL, AR-
RAY
- T911700056730

Bose L1 Pro8 Specifications

General

Tweeter	Yes
Amplifier	Built-in
Speaker type	-
Amplifier class	D
Number of drivers	8
Number of speakers	1
Woofer diameter (imperial)	13 \
Tweeter diameter (imperial)	2 \
Frequency range	- Hz
RMS rated power	300 W
Speakers RMS power	60 W
Sound pressure level (max)	118 dB
Wi-Fi	No
AUX in ports	2
Connectivity technology	Wired & Wireless
Type	Freestanding Public Address (PA) system
Control type	Buttons, Rotary
Product type	2.1 portable speaker system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Power source type	AC

Weight and Dimensions

Depth	440 mm
Width	318 mm
Height	2005 mm
Weight	18000 g
