Bose L1 Pro8 Service Manual

13
Main Part List
L1 Pro8 I/O Panel Assy (see Figure 3)
Item
Number
Description Bose Material
Number
Vendor Part
Number
Notes
1 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500012350
2 SCREW, M3.0XL9, BLUE ZINC+NYL - T15130091C610
3 SCREW, T3XL8, 1.3P, NICKEL - T153300612631
4 SHIELD COVER, SECC - T130207700100
5 SCREW, T3.0XL12, 1.06P NICKEL - T15330122F610
6 WASHER, OD5.0XID3.1XT2.0 - T181200000270
7 PLATE HEATSINK, AL1050 - T130203100100
8 THERMAL PAD 1, HEATSINK 844029-0110 T181700001640
9 THERMAL PAD 2, HEATSINK 844030-0110 T181700001630
10 THERMAL PAD, H500 856799-0110 T181700001730
11 HEATSINK, MOS, AL - T130203200200
12 SPACER, PA66-ROW 94V0 - T100461800100
13 THERMAL PAD, EXTRUSION 845032-0110 T181700001650
14 VOLUME, CONNECT CABLE, 10PIN - T641700180000
15 VOLUME, CONNECT CABLE,10PIN - T641700180100
16 EVA, 38 DEGREE, BLACK - T180500032640
17 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031130
18 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031120
19 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031150
20 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003070
21 ASSY, PCB, ANTENNA AND CABLE 796036-001S T690800019100
22 FENCE COVER, RF, CU-NI ALLOY - T130196900100
23 FENCE, RF, CU-NI ALLOY - T130196800100
24 ASSY, PCBA, MAIN-I/O, SVCE 861373-001S T910000070280
25 POWER, LIGHT GUID - T100402400100
26 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500032740
27 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003040
28 BUTTON, SELECTION, PC+ABS - T100403500100
29 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500032750
30 EVA, 38 DEGREE, ADHESIVE, BLACK,
3M 9448A
- T180500032680
31 POWER, BUTTON, PC+ABS - T100401900100
32 RING, POWER, BUTTON - T100402100100

Bose L1 Pro8 Specifications

General

Tweeter	Yes
Amplifier	Built-in
Speaker type	-
Amplifier class	D
Number of drivers	8
Number of speakers	1
Woofer diameter (imperial)	13 \
Tweeter diameter (imperial)	2 \
Frequency range	- Hz
RMS rated power	300 W
Speakers RMS power	60 W
Sound pressure level (max)	118 dB
Wi-Fi	No
AUX in ports	2
Connectivity technology	Wired & Wireless
Type	Freestanding Public Address (PA) system
Control type	Buttons, Rotary
Product type	2.1 portable speaker system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Power source type	AC

Weight and Dimensions

Depth	440 mm
Width	318 mm
Height	2005 mm
Weight	18000 g
