34
TAP COMMANDS CONTINUED
7. Software Version
7.1 “sys ver”
The unit will reply with something similar to
the following, significant digits are bold:
BoseApp version: 2.1.12.12569.366803
epdbuild.rel_2.x.hepdswbld05.2013-09-
12T18:23:09
8. Display Test (OLED)
8.1 Enter TAP command ‘local_services on’
8.2 Press Control C and then type ‘e’ and
then enter.
8.3 At the taigan login, enter TAP command
‘root’.
8.4 Enter TAP command ‘cd /opt/Bose’
8.5 At the root@Taigan:Bose prompt, enter
the following TAP commands to display
different sections of the display.
cat oled_pattern_left_bar.raw > /dev/fb
cat oled_pattern_center_bar.raw > /dev/fb
cat oled_pattern_right_bar.raw > /dev/fb
cat oled_pattern_cols.raw > /dev/fb
cat oled_pattern_rows.raw > /dev/fb
cat oled_pattern_outline.raw > /dev/fb
8.6 To return unit to normal mode, Enter TAP
command ‘rm /mnt/nv/local_services’
Enter TAP command ‘sys reboot’
9. Factory Default
9.1 Enter TAP command ‘sys factorydefault’
