16 EN
SETUP
Wall‑mount the VB‑S
For best performance, follow these recommendations when setting up the
VB-S on a wall:
See General Mounting Guidelines (Page14) first.
When determining where to attach the wall-mount bracket to the wall,
make sure there is enough space around the bracket to fit the VB-S:
There must be at least 3.8cm (1.5in) above the wall-mount bracket.
This will allow you to “hang” the VB-S on it (Step6) and to adjust the
angle of the VB-S. It will also provide enough space to access the rear-
panel connections on the VB-S.
There must be at least 11.4cm (4.5in) below the wall-mount bracket.
This will allow you to hang the VB-S vertically during installation to
insert cables and to adjust the angle of the VB-S.
The space must be at least 31.8cm (12.5in) wide with the wall-mount
bracket in the center of it. This is necessary to accommodate the VB-S
plus space to access the acoustic port on the sides of the VB-S (there
should be 2.5cm (1.0in) on each side).
Only use the included hardware to wall-mount this product.
Note: Some additional tools are required.
Note: Read the included Important Safety Instructions before
continuing.
