Bose VIDEOBAR VB-S User Manual

39 EN
OPERATION
Manage Audio Levels
The Bose Videobar VB-S has three audio inputs: its microphones, USB
audio, and Bluetooth audio.
The VB-S also has two audio outputs: its speaker and USB audio.
The real-time levels of all of these signals can be seen in the Meters tab of
the Bose Work Configuration app or WebUI.
Local Audio Playback
Music or audio over the USB or Bluetooth inputs are played back through
the VB-S speaker (the near end).
During meetings, this USB audio will not be sent to the other participants
(the far end), but Bluetooth audio will be sent to the far end if the meeting
audio and Bluetooth audio are "bridged." Bridging is enabled in the VB-S
by default, but you can disable or reenable it by using the Bose Work
Configuration app or WebUI or the Bose Work Management app (see
Software Applications (Page23)).
Meeting Audio
The VB-S microphone audio is sent to the other participants (the far end)
via the USB output after the Acoustic Echo Cancellation (AEC) feature.
If local audio playback is sent over the USB input, it will play over the
VB-S speaker, but the AEC feature will remove the music from the VB-S
microphone audio pick-up before sending it to the far end.
If you wish to send local audio playback to the far end, share the audio
playback app within your meeting software.
To mute or unmute the VB-S microphone, use the Mute button on the
remote control. When the microphone is muted, all lights in the light bar
will be lit solid red.

Bose VIDEOBAR VB-S Specifications

General

Brand	Bose
Model	VIDEOBAR VB-S
Category	Conference System
Language	English
