156
Machine specifications
SPECIFICATIONS
Item Specification
Weight 38 kg (83 lb)
Machine size 512 (W) × 587 (D) × 762 (H) mm
(20-5/32 (W) × 23-7/64 (D) × 30 (H) inches)
Embroidery speed Speed range / Max.: 1,000 spm, Min.: 400 spm
Depending on the embroidery frame, maximum stitches in one minute is 600.
Hook Type Vertical fully rotary hook
Hook size Normal size (Type L)
Needle HA130EBBR / #11
Number of needle 6 needles
Thread tension Manual
Thread trimming Upper and bobbin thread
Thread breakage sensor Yes / Upper thread and bobbin thread
Automatic needle
threader
Yes
Connecting your
machine to PC
Compatible interfaces
USB
*1
/ Wireless LAN
*2
Compatible models IBM PC with a USB port as standard equipment
IBM PC-compatible computer equipped with a USB port as standard equipment
Compatible operating
systems
Microsoft Windows 8.1, Windows 10
Memory Embroidery patterns 10 MB
Data Types
Embroidery patterns
*3
.pes .phc .phx .dst .pen
Data Size Embroidery patterns Up to 300 mm (W) × 200 mm (H)
(approx. 11-3/4 inches (W) × 7-7/8 inches (H))
.pes files that can be
displayed
Up to 500,000 stitches
Up to 127 color changes
Types of USB Devices/
Media that can be Used
*4
Embroidery patterns Embroidery data can be saved to or recalled from USB media. Use media that
meets the following specifications:
• USB Flash drive (USB Flash memory)
Embroidery data can be recalled only:
• USB external CD/DVD drives
Condition of the [Eco
Mode] and [Shutoff
Support Mode]
[Eco Mode] Available time [OFF], 10 - 120 (minute)
“Start/Stop” button Green flashing
Suspended function Machine light, Embroidery crosshair positioning laser,
Screen display
After recovering The machine starts from the previous operation.
[Shutoff Support Mode] Available time [OFF], 1 - 12 (hour)
“Start/Stop” button Green slow flashing
Suspended function All functions
After recovering An error message appears.
You need to turn off and on the machine to restart.
