7. USING THE OPERATION PANEL (ADVANCED OPERATIONS)
BAS-342G
44
<Clearing method>
1
TEST indicator illuminates, MENU indicator flashes
While pressing the TEST key, press the SELECT key.
• Switch to user program recording mode. Check that
the menu indicators are flashing.
2
MENU indicator switches off
Press a function key from F1 to F4.
• Switch to cycle program recording mode.
Press the function key (F1 to F4) or press the or
key to select the cycle program number to clear.
3
Press the RESET key.
• The buzzer will sound and the cycle program with the number selected will
be cleared.
NOTE: If you clear all user programs after any cycle programs have been recorded, all recorded cycle programs will
also be cleared.
7-9. Direct selection (combination table)
You can use the function keys to directly select user program numbers and cycle program numbers.
U1 to U4 and C-1 to C-4 can be selected using function keys F1 to F4.
U5 to U10 and C-5 to C-9 can be selected by simultaneously pressing combinations of function keys F1 to F4 (addition).
U5/C-5 U6/C-6 U7/C-7
Or
Or
Or
U8/C-8 U9/C-9 U10
4970Q
4450Q
Clearing all cycle programs
Press and hold the RESET key for 2 seconds or more.
• The buzzer will sound and the all cycle programs will be cleared.
