2. SPECIFICATIONS
2
KE-436C
2. SPECIFICATIONS
2-1. Specifications
Stitch formation Single needle lock stitch
Maximum sewing speed 2,500 rpm (Pitch 3 mm)
Maximum pattern size 100 × 60 mm max.
Feed mechanism R-θ intermittent feed mechanism (pulse-motor driven mechanism)
Stitch length 0.1 - 10.0 mm
Number of stitches Variable
Maximum stitch number 20,000 stitches (One pattern)
Work clamp lifter Pneumatic type
Work clamp height 25 mm max.
Rotary hook Shuttle hook (shuttle hook 2, optional)
Wiper device Standard equipment
Thread trimmer device Standard equipment
Thread take-up device Standard equipment
Stepping foot lift amount 18 mm
Stepping foot stroke 0 mm, 3 - 8 mm
Safety device built-in stopping mechanism
Data storage method 3.5 floppy disk 2HD / 1.44MB, 2DD
Motor Three-phase 400W induction motor
Weights
Machine head: 56 kg, Operation panel: 2.8 kg,
Control box: 10 - 20 kg (depending on destination)
Power source
Single-phase 110, 220 - 230, 240V
3-phase 220 - 230, 380, 400V
Maximum electric power consumption; 600VA
[Main use]
Patterns up to a maximum size of 100 mm × 60 mm can be sewn.
For plain stitching of small articles, curtain darts, etc.
Two-stage work clamp, light work clamp and inner clamping device (optional) can be used.
For attaching items, sewing labels, etc.
