Storage | 4
0870211676_RA0760A_PLUS_-0004_IM_en 19 / 68
As soon as the machine is placed at its final location:
• Remove the reinforcement bar as it can hinder a technician when performing main-
tenance tasks.
• Conserve and remount it for future machine transport.
Remove side
cover
13 mm wrench
• Replace the side cover.
WARNING
Transport and lifting.
Risk of severe injury!
• Handle the machine from its base frame with care to prevent the load from tipping
over.
• Do not use straps, ropes or other lifting means.
4 Storage
• Seal all apertures with adhesive tape or reuse provided caps.
If the machine is to be stored for more than 3 months:
• Wrap the machine in a corrosion inhibiting film.
• Store the machine indoors, dry, dust free and if possible in original packaging
preferably at temperatures between 0 ... 30 °C.
