Canon EOS-1D Mark II Digial User Manual

24
The camera can use both a CF card and SD card. There must be at
least one card installed to enable shooting.
If both cards are installed, you can select which card to record the
images. (p.61)
If you use an SD card, be sure the write protect switch is set
upward to enable writing/erasing.
1
Open the cover.
¡Flip up and turn the cover release
handle as shown by the arrow.
2
Insert the memory card into the
camera.
¡The left slot is for the CF card, and the
right slot is for the SD card.
¡Make sure the label side of the card is
on the left, then push in the card in the
direction of the <
q> arrow.
3
Close the cover.
¡Push in the cover until the cover
release handle returns to its original
position.
Installing and Removing the Memory Card
Installing the Card

Canon EOS-1D Mark II Digial Specifications

General

Sensor Type	CMOS
Effective Pixels	8.2 megapixels
Sensor Size	28.7 x 19.1 mm
ISO Sensitivity	ISO 100-1600 (expandable to 50-3200)
Autofocus Points	45
Continuous Shooting Speed	8.5 fps
LCD Screen Size	2.0 inches
Weight	1220 g (body only)
Camera Type	Digital SLR
Image Resolution	3504 x 2336
Lens Mount	Canon EF
Viewfinder	Optical (pentaprism)
Battery	NP-E3
Dimensions	156 x 157.6 x 79.9 mm
LCD Screen Resolution	230, 000 pixels
Viewfinder Coverage	100%
Shutter Speed Range	30 - 1/8000 sec
Storage Media	CompactFlash (Type I or II)
