75
Autofocus can fail to achieve focus (the focus confirmation light <o>
blinks) with certain subjects such as the following:
Subjects difficult to focus
(a) Low-contrast subjects
Example: Blue sky, solid-color walls, etc.
(b) Subjects in low light.
(c) Extremely backlit and reflective subjects
Example: Car with a reflective body, etc.
(d) Overlapping near and far objects
Example: Animal in a cage, etc.
(e) Repetitive patterns
Example: Skyscraper windows, computer keyboards, etc.
In such cases, do one of the following:
(1) Focus an object at the same distance as the subject and lock the
focus before recomposing.
(2) Set the lens focus mode switch to <
g> and focus manually.
When Autofocus Fails (Manual Focusing)
If focus cannot be achieved with the AF-assist light of a Speedlite or ST-E2,
select the center AF point. An off-center AF point may not be able to achieve
focus.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon EOS-1D Mark II Digial and is the answer not in the manual?

Canon EOS-1D Mark II Digial Specifications

General IconGeneral
Sensor TypeCMOS
Effective Pixels8.2 megapixels
Sensor Size28.7 x 19.1 mm
ISO SensitivityISO 100-1600 (expandable to 50-3200)
Autofocus Points45
Continuous Shooting Speed8.5 fps
LCD Screen Size2.0 inches
Weight1220 g (body only)
Camera TypeDigital SLR
Image Resolution3504 x 2336
Lens MountCanon EF
ViewfinderOptical (pentaprism)
BatteryNP-E3
Dimensions156 x 157.6 x 79.9 mm
LCD Screen Resolution230, 000 pixels
Viewfinder Coverage100%
Shutter Speed Range30 - 1/8000 sec
Storage MediaCompactFlash (Type I or II)
