Canon EOS-1D Mark II Digial User Manual

39
The date/time (back-up) battery’s service life is about 10 years. If the
date/time is reset, replace the back-up battery with a new CR2025
lithium battery as described below.
1
Set the <4> switch to <2>
and remove the battery pack.
¡The back-up battery is on the ceiling of
the battery compartment.
2
Remove the back-up battery
cover.
¡As shown in the diagram, loosen the
screw to remove the cover.
3
Remove the battery.
4
Install a new back-up battery.
¡The plus side of the battery must face
up.
5
Attach the cover.
¡Install the battery and turn the <4>
switch to <1>. The date/time will be
displayed on the LCD monitor. Set the
the date/time.
Replacing the Date/Time Battery
(+)

Canon EOS-1D Mark II Digial Specifications

General

Sensor Type	CMOS
Effective Pixels	8.2 megapixels
Sensor Size	28.7 x 19.1 mm
ISO Sensitivity	ISO 100-1600 (expandable to 50-3200)
Autofocus Points	45
Continuous Shooting Speed	8.5 fps
LCD Screen Size	2.0 inches
Weight	1220 g (body only)
Camera Type	Digital SLR
Image Resolution	3504 x 2336
Lens Mount	Canon EF
Viewfinder	Optical (pentaprism)
Battery	NP-E3
Dimensions	156 x 157.6 x 79.9 mm
LCD Screen Resolution	230, 000 pixels
Viewfinder Coverage	100%
Shutter Speed Range	30 - 1/8000 sec
Storage Media	CompactFlash (Type I or II)
