Canon EOS Rebel T6 User Manual

271
Remote Switch RS-60E3 (sold separately) comes with an approx. 60 cm/
2.0 ft cord. When connected to the camera’s remote control terminal, it
can be pressed halfway and completely, just like the shutter button.
When you use the self-timer, bulb, or a remote switch and do not look
through the viewfinder, stray light entering the viewfinder can cause the
picture to look dark. To prevent this, use the eyepiece cover (p.33)
attached to the camera strap.
During Live View shooting and movie shooting, attaching the
eyepiece cover is unnecessary.
1
Detach the eyecup.
 Push the bottom of the eyecup to
detach it.
2
Attach the eyepiece cover.
 Slide the eyepiece cover down into
the eyepiece groove to attach it.
 After you finish shooting, detach the
eyepiece cover and attach the
eyecup by sliding it down into the
eyepiece groove.
F Using a Remote Switch
Using the Eyepiece Cover
Remote Controller RC-6, RC-1, and RC-5 (all sold separately) cannot be
used with this camera.

Canon EOS Rebel T6 Specifications

General

Camera Type	Digital SLR
Sensor	CMOS
Effective Megapixels	18.0 MP
Sensor Size	22.3 x 14.9 mm
ISO Range	100-6400 (expandable to 12800)
Image Processor	DIGIC 4+
Autofocus Points	9
Continuous Shooting	3 fps
Viewfinder Type	Optical (pentamirror)
Viewfinder Coverage	95%
Screen Size	3.0 inches
Screen Resolution	920, 000 dots
Video Resolution	1920 x 1080 (Full HD)
Video Format	MOV (H.264)
Built-in Flash	Yes
Lens Mount	Canon EF/EF-S
Storage Media	SD/SDHC/SDXC
Connectivity	Wi-Fi, NFC
Battery	LP-E10
Battery Life	Approx. 500 shots
Shutter Speed	30-1/4000 sec
External Flash	Yes (Hot Shoe)
Dimensions	129.0 x 101.3 x 77.6 mm
Weight	485 g (body only)
