Canon imagePROGRAF iPF765 Basic Guide

Cause Corrective Action
You have attempted to print a test print sheet or other
printer status information on a sheet, but no sheet is
loaded.
(See "Loading and Printing on Rolls.") →User's Guide
Regular printing is selected, but a roll is loaded.
Regular printing is selected, but a roll is loaded.
Cause Corrective Action
A print job for printing on
sheets was sent when a
roll is loaded.
1. Press ▲ or ▼ to select Remove Roll Paper, and then press the OK button to stop printing.
2. After removing the roll, load and print on a sheet of the type and size of paper you have specified in the
printer driver.
(See "Removing the Roll from the Printer.") →P.15
(See "Loading and Printing on Sheets.") →User's Guide
Paper jam
Paper jam
"Push the release lever back."
Cause Corrective Action
A paper jam occur-
red in the printer
during printing.
1. Push the Release Lever back and remove the jammed paper.
(See "Clearing Jammed Roll Paper.") →P.84
(See "Clearing a Jammed Sheet.") →P.87
2. Load the paper.
3. Pull the Release Lever forward.
4. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the OK
button.
Printing will resume, starting from the page on which the error occurred.
(See "Loading Rolls in the Printer.") →P.12
(See "Loading Sheets in the Printer.") →P.18
"Manually rewind the roll all the way and press OK."
Cause Corrective Action
A paper jam occurred
when advancing the
paper.
1.
Rewind paper on the Roll Holder manually, all the way, and then press the OK button.
2. Load the paper.
3. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the OK
button.
Printing will resume, starting from the page on which the error occurred.
(See "Loading Rolls in the Printer.") →P.12
Paper is crooked.
Paper is crooked.
Cause Corrective Action
Paper loaded crooked was detected when the paper was advanced.
Follow these steps to reload the roll.
1.
Push the Release Lever back.
2. Adjust the right edge of the roll to make it parallel to the orange
Paper Alignment Line.
3. Pull the Release Lever forward.
(See "Loading Rolls in the Printer.") →P.12
iPF765 Regular printing is selected, but a roll is loaded.
Basic Guide
Error Message Messages regarding paper
115

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
