Canon imagePROGRAF iPF765 Basic Guide

Menu Structure
Menu Structure
The menu structure is shown categorized by tab. The * on the right side of an item indicates the default value.
The printer menu is classified into regular menu items available when no print job is in progress and menu during
printing items only available while printing is in progress. see "Printer Menu Operations."
→User's Guide
Regular menu Menu during printing
Paper Menu Not displayed
Ink Menu The same Ink Menu as normal is displayed.
Job Menu The same Job Menu as normal is displayed.
Set./Adj. Menu A limited Set./Adj. Menu containing the following items is displayed.
• Adj. Fine Feed (*1)
• Printer Info
*1: Only displayed in the menu during printing. Not displayed in the regular menu.
For instructions on menu operations,
see "Menu Operations."
→P.44
For details on menu items, see "Menu Settings."
→User's Guide
Paper Menu
The Paper Menu is not displayed during printing.
First Level Second Level Third Level Fourth Level Fifth Level
Load Paper Roll Paper ┋ Cut Sheet
Eject Paper
Chg. Paper Type (*1) Roll Paper (The paper type is displayed here.) (*1)
Cut Sheet (The paper type is displayed here.) (*1)
Chg. Paper Size Sheet Size (The size of paper is displayed here.) (*2)
CustomPaperSize (Set the length and width)
Roll Length (*3) (Set the length)
Roll Width (*4) (Set the width)
ManageRemainRoll Off *┋ On
Paper Details (The paper type is dis-
played here.) (*1)
Head Height Automatic *┋ Highest ┋ High ┋ Standard ┋
Low ┋ Lowest ┋ Super Low
Skew Check Lv. High Accuracy ┋ Standard *┋ Loose ┋ Off
Cutting Mode (*6) Automatic ┋ Eject ┋ Manual
Cut Speed Fast ┋ Standard ┋
Slow
Trim Edge First Automatic ┋ Off ┋
On
CutDustReduct. Off ┋ On
VacuumStrngth Automatic *┋ Strongest ┋ Strong ┋ Standard
┋ Weak ┋ Weakest
Scan Wait Time Dry time Off *┋ 1 sec. ┋ 3
sec. ┋ 5 sec. ┋ 7
sec. ┋ 9 sec.
Area (*5) Entire area *┋ Lead-
ing edge
Roll DryingTime Off ┋ 30 sec. ┋ 1 min. ┋ 3 min. ┋ 5 min. ┋ 10
min. ┋ 30 min. ┋ 60 min.
NearEnd RollMrgn 3mm ┋ 20mm
NearEnd Sht Mrgn 3mm ┋ 20mm
Bordless Margin Automatic ┋ Fixed
Width Detection Off ┋ On *
Menu Structure iPF765
Basic Guide
Printer Parts Operations and Display Screen
48

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
