Canon IP2800 series User Manual

Adjusting Intensity
You can dilute (brighten) or intensify (darken) the colors of the overall image data during printing.
The following sample shows the case when the intensity is increased so that all colors become more intense
when the image data is printed.
No adjustment Higher intensity
The procedure for adjusting intensity is as follows:
You can also set intensity on the Quick Setup tab by choosing Photo Printing under Commonly Used
Settings, and then choosing Color/Intensity Manual Adjustment under Additional Features.
1.
Open the printer driver setup window
2.
Select the manual color adjustment
On the Main tab, select Manual for Color/Intensity, and click Set....
The Manual Color Adjustment dialog box opens.
3. Adjust intensity
Moving the Intensity slider to the right intensifies (darkens) the colors, and moving the slider to the left
dilutes (brightens) the colors.
You can also directly enter a value linked to the slider. Enter a value in the range from -50 to 50. The
current settings are displayed in the settings preview on the left side of the printer driver.
After adjusting each color, click OK.
166

Canon IP2800 series Specifications

General

Print Technology	Inkjet
Max Print Resolution	4800 x 600 dpi
Connectivity	USB
Output Tray Capacity	50 sheets
Dimensions	426 x 235 x 134 mm
Print Speed (Black)	8.0 ipm
Print Speed (Color)	4.0 ipm
Paper Sizes	A4, Letter, Legal, Envelopes (DL, COM10)
Paper Compatibility	Plain Paper, Photo paper, Envelopes
Paper Input Capacity	60 sheets
Interface	USB
Operating System Support	Windows XP/Vista/7, Mac OS X v10.4.11 or later
