Canon IP2800 series User Manual

Aligning the Print Head Position from Your Computer
Print head alignment corrects the installation positions of the print head and improves deviated colors and
lines.
The procedure for performing print head alignment is as follows:
Note
• If you are adjusting the head position while the software is being installed from the Setup CD-ROM,
start from Step 3.
Print Head Alignment
1.
Open the printer driver setup window
2.
Click Print Head Alignment on the Maintenance tab
The Start Print Head Alignment dialog box opens.
3.
Load paper in the printer
Load three sheets of A4 size or Letter size plain paper into the rear tray.
4.
Execute head alignment
Make sure that the printer is on and click Align Print Head.
Follow the instruction in the message.
5.
Check the printed pattern
Enter the numbers of the patterns with the least amount of streaks in the associated boxes.
Even if the patterns with the least amount of streaks are clicked in the preview window, their numbers
are automatically entered in the associated boxes.
71

Canon IP2800 series Specifications

General

Print Technology	Inkjet
Max Print Resolution	4800 x 600 dpi
Connectivity	USB
Output Tray Capacity	50 sheets
Dimensions	426 x 235 x 134 mm
Print Speed (Black)	8.0 ipm
Print Speed (Color)	4.0 ipm
Paper Sizes	A4, Letter, Legal, Envelopes (DL, COM10)
Paper Compatibility	Plain Paper, Photo paper, Envelopes
Paper Input Capacity	60 sheets
Interface	USB
Operating System Support	Windows XP/Vista/7, Mac OS X v10.4.11 or later
