Canon XL H1S User Manual

11
Introduction
Components Guide
External control mode*
VCR/PLAY mode
Power off
Manual
Auto
Shutter-Priority
Aperture-Priority
Spotlight
Night
Easy Recording
Left side view
Recording
programs
dial
* Reserved mode for future software development.
LIGHT button
END SEARCH button ( 41)
MODE SELECT switch ( 40)
FRAME RATE switch ( 50)
AUDIO OUTPUT CH button ( 90)
indicator
Side panel ( 143)
Viewfinder attachment bracket ( 21)
EVF1 color viewfinder socket ( 21)
EVF2 external monitor/viewfinder socket ( 85, 155)
EVF PEAKING/EVF MAGNIFYING buttons ( 46)
EXP. LOCK button ( 69)/PUSH AE button ( 66)
LENS RELEASE switch ( 27)
SET button ( 33)
SELECT dial ( 33)/IRIS dial ( 65, 68)
(record review) button ( 39)
BARS/FADE SELECT button ( 83)
BARS/FADE ON/OFF button ( 83)
MENU button ( 33)
GAIN dial ( 70)
WHITE BALANCE dial ( 71)
WHITE BALANCE button ( 71)
STANDBY button ( 37)
INPUT SELECT switch (CH1) ( 58)
REC LEVEL switch (CH1) ( 59)
INPUT SELECT switch (CH2) ( 58)
REC LEVEL switch (CH2) ( 59)
XLR REC CH SELECT switch (CH1/CH2) ( 58)
CH2 dial ( 59)
FRONT MIC ATT. switch (CH/CH2) ( 58)
CH1 dial ( 59)
COPY
