136
1
In playback modes the default setting is [OFF].
[MARKERS]: You can display the on-screen markers to help you accurately frame your subject. Select from
a center marker, a horizontal level marker or a grid. You can also adjust the intensity of the markers display
(109).
[ASPECT GUIDE]: Use the aspect ratio guides as a reference to accurately frame subjects. You can select to
display the aspect guides for 4:3, 13:9, 14:9, 1.66:1, 1.75:1, 1.85:1 or 2.35:1 (Cinemascope).
[SAFETY ZONE]: The safety zone guide shows a frame including 80% or 90% of the screen area. Use it as
a reference to accurately frame subjects.
 DISPLAY SETUP/
Menu item (Submenu item and) Setting options
EVF SETUP EVF BW MODE ON, OFF 24
BRIGHTNESS 0 (-23 to 22)
CONTRAST 0 (-23 to 22)
COLOR 0 (-3 to 3)
SHARPNESS 2 (1 to 4)
PEAKING SETUP PEAKING1 GAIN: 8 (OFF to 15) – – 46
FREQUENCY: 2 (1 to 4)
PEAKING2 GAIN: 15 (OFF to 15)
FREQUENCY: 1 (1 to 4)
LANGUAGE DEUTSCH, ENGLISH, ESPAÑOL, FRANÇAIS,
ITALIANO, POLSKI, , ,
35
MARKERS OFF, LEVEL MARK., CENT.MARK., GRID MARKER – – –
ASPECT GUIDE OFF, 4:3, 13:9, 14:9, 1.66:1, 1.75:1, 1.85:1,
2.35:1
– – – –
SAFETY ZONE OFF, 80%, 90% – – – –
ZEBRA ON, OFF – – 73
ZEBRA LEVEL 70, 75, 80, 85, 90, 95, 100 – – 73
TV SCREEN
1
ON, OFF 80
AUDIO LEVEL ON, OFF – – 59
GUIDE INFO OFF, CUSTOM KEYS, D/T DISPLAY – – 39
CUSTOM KEY ON, OFF – – 79
DATA CODE DATE, TIME, DATE & TIME, CAMERA DATA,
CAM.& D/T
– – – 117
6SEC.DATE ON, OFF – – – 117
UB DISPLAY ON, OFF – – 56
 SYSTEM SETUP/
Menu item (Submenu item and) Setting options
CUSTOM KEY1 TIME CODE, INDEX WRITE, ZEBRA, VCR STOP, TV
SCREEN, TC HOLD, AUDIO LEVEL, EVF BW MODE,
MAGN.B.LOCK, SHTR B.LOCK, AE D.LOCK, E.LCK
B.LCK, FB, FLIP EVF, SDI OUTPUT
1
, FOCUS LIMIT,
(NONE)
– – – 79
TIME CODE, TV SCREEN, DATA CODE, AUDIO
LEVEL, TC HOLD, EVF BW MODE, SDI OUTPUT
1
,
(NONE)
– – – 79
ZEBRA, TV SCREEN, EVF BW MODE,
MAGN.B.LOCK, SHTR B.LOCK, AE D.LOCK, E.LCK
B.LCK, FB, FLIP EVF, SDI OUTPUT
1
, FOCUS LIMIT,
(NONE)
– – – 79
TV SCREEN, EVF BW MODE, SDI OUTPUT
1
, (NONE) – – – 79
