90
Audio Output
Selecting the Audio Channel
You can select the channel for audio signal output from the CH1/CH2 and the (headphone)
terminals.
Repeatedly press the AUDIO OUTPUT CH
button to change the audio channel.
• Pressing the button will cycle between the audio
channels in the following order: CH1/CH2
CH1/CH1 CH2/CH2 ALL CH/ALL CH
CH1/CH2.
• During playback of a tape recorded with 4-channel
audio (using another device) or while recording
external video with 4-channel audio from the HDV/DV
terminal, the output channels will be: CH1·3/CH2·4
CH1·3/CH1·3 CH2·4/CH2·4 ALL CH/ALL CH.
Selecting the Audio Output Level
You can boost the level of the audio output signal from the CH1/CH2 terminals from 1 Vrms to
2 Vrms (+6 dB).
Open the menu and select [AUDIO SETUP]. Select [OUTPUT LEVEL], select a setting
option and close the menu.
Selecting the Audio Monitor
Open the menu and select [AUDIO SETUP]. Select [AUD.M.SET], select a setting option
and close the menu.
• You can also select the audio monitor using the wireless controller.
• If you selected [MIX/VAR.], adjust the mix balance with the [MIX BALANCE] setting or using the MIX
BALANCE buttons on the wireless controller.
MENU
( 33)
AUDIO SETUP OUTPUT LEVEL•••1Vrms
MENU
( 33)
AUDIO SETUP AUD.M.SET
•••
CH 1/2
COPY
