ENGLISH
µC
2
SE - +030220426 - rel. 2.0 - 03.08.2009
Fig. 3.e.a
Fig. 3.e.b
3.5 WATER/WATER chiller
3.5.1 Single circuit
3.5.2 Two circuits
Key:
1 water condensing temperature probe
2 condensator
3 fl ow switch
4 outlet evaporator probe
5 evaporator
6 antifreeze heater
7 inlet evaporator probe
8 compressor 1
9 high pressure
10 compressor overload
11 low pressure
12 water pump
13 compressor 2
Key:
1 water condensing temperature probe 1 and 2
2 condensator 1 and 2
3 fl ow switch
4 outlet evaporator probe
5 evaporator
6 antifreeze heater 1 and 2
7 compressor 1
8 high pressure 1 and 2
9 compressor overload 1 and 2
10 low pressure 1 and 2
11 inlet evaporator probe
12 water pump
13 compressor 2
14 compressor 3
15 compressor 4
