8. DIMENSIONS
The following are the mechanical dimensions of each component in the µC
2
SE controller; all the values
are expressed in millimetres.
Note: the dimensions include the free connectors inserted.
Fig. 8.a
Fig. 8.b Fig. 8.c
Fig. 8.d
MCH200000* µC
2
SE panel mounting version
drilling template
71x29 mm
overall dimensions 91,5x36x5 mm
panel mounting
Expansion board for µC
2
SE
CONVONOFF0 and CONV0/10 A modules
DIN rail mounting
RS485 serial card: codeMCH2004850
